W-31 Epoxy Cove Gel
W-31 consist of a high viscosity, nonylphenol-free, epoxy resin, a thickened, cycloaliphatic amine reactant, and a specialty trowel aggregate blend.
Overview
W-31 consist of a high viscosity, nonylphenol-free, epoxy resin, a thickened, cycloaliphatic amine reactant, and a specialty trowel aggregate blend. This combination achieves a rheology and consistency that makes it easy to trowel but also fast to return to its resting state, especially in vertical applications.
Uses and Benefits
W-31 is most often used in application as a cove base around the perimeter of an installation to prevent damage and/or contamination around the base of walls as well as provide containment where needed. It provides a seamless transition from the floor to wall.
Limitations
W-31 is designed to be applied between 1/8” to 1/4” thickness; this is application dependent. It is not intended to be used as a finish coat as it will amber. Cooler temperatures will increase cure times. Warmer temperatures will decrease working and cure times. Verify that substrate temperature is above 5 degrees of dewpoint during application and cure of material to avoid a potential amine blush.
Preparation
The preparation method for each project is determined by a full understanding of the substrate to be coated, the chemistry of the coating system being used, the coating system thickness, and numerous other factors. The coating installer should fully read and understand ICRI Guideline NO. 310.2R-2013 and OSHA 29 CFR 1926.1153 before starting preparatory work. The aim, of preparing a substrate for coating applications, is to roughen the surface, remove weak layers, contaminants, dirt, debris and present a solid, clean, dry substrate for the primer. If unsure as to the level of preparation needed contact Polymer Nation at Lab@polymerNation.com.
Technical Data
At a glance — the specs most teams decide on.
- Shore Hardness @ 24 Hours
- D65Shore D
- Shore Hardness @ 7 Days
- D78Shore D
- Gloss @ 60° Angle
- 60-70
- VOCs of Mixed Material
- <50 g/lEPA Method 24
- Color Scale per ASTM D1500
- 0.5-1.0
- Solids by Volume (Mixed)
- 100%
- Working Time
- 25-35 minutes
- Gel Time
- 45 minutes
- Dry to Touch
- 6-8 hours
- Through Dry
- 12-16 hours
- Dry to Lightly Use
- 18-24 hours
- Full Cure
- 7 days
- Number of Components
- 3
- Mix Ratio (Liquids by Volume)
- 2:1
- Mixed Viscosity @ 25°C/77°F
- 4500 cP 25°C/77°FLiquids only
- Ideal Application Temperature
- 60-85°F
- Application Thickness
- 1/8” to 1/4”
- Coverage Per Mix
- 2” Cant: 62 feet; 4” Cove with 1” radius: 36 feet; 6” Cove with 1” radius: 32 feet
- Number of Mixes per Kit
- 1Mix: Part A - 0.5 gal, Part B - 0.25 gal, Part C - 45-50 lbs. Aggregate
- Storage Temperature
- 60-80 degrees F
Colors & Packaging
Colors
Clear & Color Packs
Packaging
- Available sizes
- 3 Quarts + 45-50 lbs. Aggregate
Mixing & Application
It is always recommended to mix the entire kit, whenever possible, to avoid off-ratio mixtures. Mix ratio is 2 parts W-31 Part A (0.5 gal.) to 1 part W-31 Part B (0.25 gal.) to 45 lbs. PN 1324 trowel aggregate or 50 lbs. PN 1321 L decorative quartz trowel aggregate. Combine all of part A and B into a single container, large enough to except the entire kit. Mix using a 350 RPM mixer using an appropriate mixing blade for 1 - 2 minutes making sure to not introduce excessive air into the material; then, under mixing, add desired trowel aggregate (PN 1324 or PN 1321L).
Disposal: Dispose of material, containers, solvents, etc., per Federal, State and local guideline, rules and laws.
